IHF50-32-200 fluoroplastic lined chemical centrifugal pump with WB2 type external mechanical seal

- Pump name: fluorine plastic lined chemical centrifugal pump

- Type: centrifugal pump

- Pump model: IHF50-32-200

- Pump brand: ATACH

- Structure: horizontal with coupling

- Number of impeller: 1

- Rated flow: 12.5m3h

- Rated lift: 50 m

- Supporting power speed: 7.5Kw2900 RPM

- Power supply: 3-phase 380V50HZ (accept customized special voltage, special frequency, explosion-proof, YE3 energy-saving motor)

- Material of flow parts: fluorine plastic lining

- Seal form: mechanical seal

- Inlet and outlet diameter: 5032mm

- Required cavitation allowance: 3 m

- The main application conditions: any concentration of strong acid, strong alkali, strong oxidant, organic solvent and other strong corrosive occasions.

If you need other specifications or parameters of IHF series, please contact our sales staff for details.
