IHF50-32-160 fluoroplastic centrifugal pump

- Pump name: : fluorine plastic centrifugal pump

- Type: centrifugal pump

- Pump model: IHF50-32-160

- Pump brand: ATACH

- Structure: horizontal with coupling

- Number of impeller: 1

- Rated flow: 12.5m3 /h

- Rated lift: 32 m

- Supporting power/speed: 4 Kw/2900 RPM

- Power supply: 3-phase /380V/50HZ (accept customized special voltage, special frequency, explosion-proof, YE3 energy-saving motor)

- Material of flow parts: fluorine plastic lining

- Seal form: mechanical seal

- Inlet and outlet caliber: 50*32 mm

- Required cavitation allowance: 3 m

- The main application conditions: any concentration of strong acid, strong alkali, strong oxidant, organic solvent and other strong corrosive occasions.

If you need other specifications or parameters of IHF series, please contact our sales staff for details.
