IMD40-25-160 fluorine plastic corrosion resistant magnetic pump

- Pump name: fluorine plastic corrosion resistant magnetic pump

- Type: Magnetic pump

- Pump model: IMD40-25-160

- Pump brand: ATACH

- Structure: horizontal direct connection

- Number of impeller: 1

- Rated flow: 6 m3/h

- Rated lift: 33 m

- Supporting power/speed: 3 Kw/2900 RPM

- Power supply: 3-phase /380V/50HZ (accept customized special voltage, special frequency, explosion-proof, YE3 energy-saving motor)

- Material of flow parts: steel lined with fluorine plastic

- Seal form: mechanical seal

- Inlet and outlet caliber: 40*25 mm

- Required cavitation allowance: 3 m

- Main application conditions: Widely used in chemical industry, acid, alkali, smelting, rare earth, pesticides, dyes, medicine, paper making, electroplating, point hydrolysis, pickling and other industries, can transport any concentration pickling, alkaline, oil, rare and precious liquid, toxic liquid, volatile chemical media, especially easy to leak, flammable, explosive liquid transport.

If you need other specifications or parameters of IMD series fluoroplastic magnetic pump, please contact our sales staff for details
