GDF80-40 304 stainless steel dyeing and finishing industry special hot water pump

- Pump name: stainless steel dyeing and finishing industry special hot water pump

- Type: pipeline type centrifugal pump

- Pump model: GDF80-40

- Pump brand: ATACH

- Structure: vertical direct connection

- Number of impeller: 1

- Rated flow: 43.5m3 /h

- Rated lift: 38 m

- Supporting power/speed: 7.5Kw /2900 RPM

- Power supply: 3-phase /380V/50HZ (accept customized special voltage, special frequency, explosion-proof, YE3 energy-saving motor)

- Material of flow parts: stainless steel 304, stainless steel 316, stainless steel 316L

- Seal form: mechanical seal

- Inlet and outlet diameter: 80*80 mm

- Required cavitation allowance: 3 m

- Mainly applicable conditions: environmental protection, dyeing and finishing, machinery and machinery factory supporting, industrial and urban water supply and drainage, tunnel construction water, high-rise building water supply, HVAC refrigeration cycle, boiler water supply and other occasions.

If you need other specifications or parameters of GDF series, please contact our sales staff for details
